Raise3D E2CF – Born for Carbon Fiber – A Desktop 3D Printer Specifically Developed For Composite Materials

Technical Specifications

• Print Size (L×W×H): Single extruder: 330×240×240 mm; Dual extruder: 295×240×240 mm
• Dimensions (L×W×H): 607×596×465 mm
• Technology: FFF (Fused Filament Fabrication) technology
• Extrusion System: IDEX (Independent Dual Extruder) system
• Filament Diameter: 1.75 mm
• XYZ Axis Step Accuracy: 0.78125, 0.78125, 0.078125 micron
• Print Speed: 15–150 mm/s
• Print Bed: Flexible bed
• Maximum Bed Temperature: 110 ºC
• Heating Plate Material: Silicone
• Bed Leveling: Automatic leveling
• Power Loss Recovery: Supported
• Filament Runout Detection: Supported
• Supported Materials: PLA/ ABS/ ASA/ PETG/ PC/ PA12 CF/ PA12 CF+/ PET CF/ PET GF/PPA CF/ PPA GF/ PETG ESD/ PVA+/ PA12 CF Support/ PET Support/PPA Support
• Layer Thickness: 0.1– 0.5 mm
• Nozzle Diameter: 0.4 mm (default), 0.6/0.8 mm (optional)
• Hotend: V4P
• Maximum Nozzle Temperature: 330 ºC
• Connectivity: Wi-Fi, LAN, USB port, real-time monitoring camera
• Noise Level: < 50 dB(A) during printing
• Recommended Operating Environment: 15–30 ºC, 10–90% relative humidity, no condensation
• Storage Temperature: -25 ºC to +55 ºC, 10–90% relative humidity, no condensation
• Air Filter: HEPA air filtration system
• Net Weight: 36.6 kg
• Gross Weight (with Packaging): 43.1 kg
• Gross Weight (with Packaging and Pallet): 50.6 kg
